Installation Points:
- Free downloadable software.
- Hydro-Com can be installed on any Microsoft WindowsTM based PC (supported on Windows XP and newer).
Unique Key Features:
- Downloadable software to access, control and monitor any sensor from anywhere in the world.
- Centralise quality management and reduce costs.
- Multi-language, easy to use interface.
- Used to backup and restore sensor settings and to create a database of material calibrations for use with the sensor.
- Used by engineers to diagnose errors or upgrade sensor firmware.
- Currently available in the following languages: Chinese, English, French, German, Italian, Portuguese, Russian and Spanish.
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
