Measurement:
- Moisture
- Ambient temperature
Typical Materials:
- Animal feed
- Grain
- Biomass
- Organic material
- Agricultural material
Unique Key Features:
- Rugged, hard-wearing design for abrasive materials.
- Simple installation in mixers and conveyors.
- Choice of measurement modes for optimum sensor performance.
Belt conveyor
- Mount on belt conveyors.
Beneath the Bin
- Position below the bin gate in the main flow of the material.
Hopper
- Mount inside or under the hopper in the centre of the material flow.
Neck of the Bin
- Fit in the neck of the bin.
Wide Bin
- Mount using the extended mounting sleeve to access the centre of the material flow.
- 0023 Hydro-Probe – Clamp Ring (for use with 0024A or 0024B)
- 0024A Hydro-Probe – Flanged Mounting Sleeve (for vertical mounting of sensor, requires 0023)
- 0024B Hydro-Probe – Flanged Mounting Sleeve in stainless steel (for vertical mounting of sensor, requires 0023)
- 0025 Hydro-Probe – Standard Mounting Sleeve
- 0026 Hydro-Probe – Extension Mounting Sleeve
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
